Chapter 12. Remote Viewer (AiT Models only)
333
Gamma Adjustment
For greater control and if it is necessary to correct the gamma level for the
remote video display, use the Gamma function of the Advanced Video
Settings by clicking the Advanced button.
For gamma level, there are ten preset and four user-defined levels to choose
from. Click the drop-down menu and choose the most suitable one.
The additional options in the Advanced screen are as follows:
Option Usage
RGB Drag the slider bars to adjust the RGB (Red, Green, Blue)
values. When an RGB value is increased, the RGB component of
the image is correspondingly increased.
If you enable Set to Grayscale, the remote video display is
changed to grayscale.
Gamma This section allows you to adjust the video display’s gamma
level.
Click and drag the diagonal line at as many points as you wish to
achieve the display output you desire.
Click Save As to save up to four user-defined configurations
derived from this method. Saved configurations can be recalled
from the list box at a future time.
Click Reset to abandon any changes and return the gamma line
to its original diagonal position.
