KVM over IP Matrix System User Manual
154
5. From the Network tab, select Set IP address manually and enter the
following:
IP Address — sets the IP address for the KE device. Key in a valid
unique IP address.
Note: See Default IP Addresses, page 154, for the preconfigured
factory-default settings.
Subnet Mask — sets the subnet mask for the KE device. Key in a valid
subnet mask value.
Note: The default setting is 255.255.255.0
Default Gateway — sets the default gateway for the KE device. Key in
a valid default gateway.
6. Click Save.
Exit OSD
To exit the OSD, press [Esc] on the keyboard, click Logout; tap [Scroll Lock]
twice, or return to the OSD main page and press the front panel OSD
pushbutton (receiver only).
At this point, the receiver can connect to the transmitter to access the remote
computer (see OSD Matrix Mode, page 183 for instructions).
Default IP Addresses
The preconfigured factory-default IP addresses for the KE Series devices are
as follows:
Transmitters –
192.168.0.61
Receivers –
192.168.0.60
Note: For KE89 and KE99 Series devices, only use factory-default IP address
if the DHCP is not present or if the initial configuration is done in PTP
mode because DHCP is supported.
