ATEN KE6900T - KE8900 ST (Transmitter) Front, Rear and Side View

KVM over IP Matrix System User Manual
64
KE8900ST (Transmitter) Front, Rear and Side View
No. Component Description
1 reset button This button must be pushed with a thin object, such as the
end of a paper clip.
 Press and release to reboot the device.
 Power off, hold reset then power on the device while
pressing reset to recover from a firmware upgrade
failure.
 Press and hold it in for more then three seconds
resets the unit back to its factory default settings*.
Note: The Reset to Factory Default function resets everything but
the login information (username/password) to the factory default
settings. To reset the login information, refer to Reset All Information
on page 423.
