Optional Rack Mount
Optional rack mount kits are available as shown in the following table:
*Supports KE6900/KE6900A/KE6910/KE6912/KE6920/KE6922/KE6940/
KE6940A/KE8950/KE8952/KE9950/KE9952.
**Please refer to VE-RMK 1U user manual on how to mount these units.
Dual Rack Mount
The 2X-021G Dual Rack Mount Kit installs two KE6900/KE6900A/KE6910/
KE6912/KE6920/KE6922/KE6940/KE6940A/KE8950/KE8952/KE9950/
KE9952 units side by side in 1U of server rack space.
Transmitter Dual Rack Mount
KE8950T is the example used here.
1. Remove four screws from the units and then use the same screws to secure
the units together with the link bracket provided with the kit.
Mount Type Model
Dual Rack Mount Kit* 2X-021G
Single Rack Mount Kit* 2X-031G
Video Extender Rack Mount Kit**
(for KE6900ST, KE8900ST,
KE8900SR and KE9900ST)
VE-RMK 1U
