Chapter 3. OSD Operation
169
After entering the information, click Save.
ATC Version
The ATC version is only supported with ATC models using firmware version
v7.5.742 or later.
Item Description
Mode Select Extender mode for simple one-to-one (Transmitter to
Receiver) setups that are managed with the Receiver’s OSD
menu.
Note: It is not recommended to use Matrix Mode for ATC
version models.
Properties If you selected Extender mode (above) set the Transmitter IP
address for the Receiver’s Video, Audio, USB, and RS232
source signals.
Note: It is not recommended to use Matrix Mode for ATC
version models.
