KVM over IP Matrix System User Manual
170
RS232 Settings Configure the serial device settings for the Receiver. The
default settings are:
Baud Rate: 9600
Parity: None
Data Bits: 8 bits
Stop bits: 1 bit
Flow Control: None
Enable Media Select which type of media the Receiver can stream from
Transmitters: Video, Audio, USB, and RS232. For KE8950
Series models, use the radio button to set the source of the
audio signal: HDMI, Analog, or Both.
Beeper Check this box to allow the Receiver to beep when configuration
changes are made to it.
Touch Screen
Calibration
Use this button to calibrate the surface of a USB touch screen
connected to the unit. When the calibration screen appears,
touch the flashing + symbol at each corner until the process is
complete.
