Chapter 5. Browser / Telnet Operation
215
Instant Link
At the bottom of the KVM over IP Matrix Manager Main Page is the Instant
Link bar. In this section you can quickly connect Receivers to Transmitters.
The top panel provides the Receiver List, and the bottom panel provides the
Transmitter List. To create a connection, click a Receiver in the top panel and
use the drop-down menu to select a Transmitter (as shown in the image below);
or drag-and-drop Transmitters from the bottom panel to Receivers in the top
panel. Configure as many Receiver to Transmitter connections as needed, and
then click Apply.
Item Description
Instant Link The Instant Link bar provides access to quickly connect
Receivers to Transmitters. Click the bar to open the
panel, click again to minimize the panel. The top panel
provides a list of all the Receivers discovered on the
LAN.Click a Receiver and use the drop-down menu to
select a Transmitter.
Transmitter List Click the Transmitter List bar to open the panel. The
panel provides a list of all the Transmitters discovered on
the LAN. Drag-and-drop Transmitters in the bottom panel
to Receivers in the top panel to establish connections.
The panel size of the Transmitter List is adjustable by
clicking-and-dragging its border.
Location Use the drop-down menu to select a location to filter the
Receivers or Transmitters displayed on the page.
Ratio Use the drop-down list to adjust the icon size of the
Receivers / Transmitters.
