ATEN KE6900T - KE6920 ATC Network Installation Diagram 1 of 2

Chapter 2. Hardware Setup
141
that if you use copper SFP modules, the module has to be removed for
the unit to switch to the LAN port’s network.
2. For USB keyboards / mice with advanced function designs, see USB
Mode, page 250.
KE6920ATC Network Installation Diagram 1 of 2
TCP/IP
LAN
KE6920T (Rear)
Cat 5e/6 cable
Optical Fiber Cable
DC 5V
Serial
Device
KE6920R (Rear)
Cat 5e/6 cable
Optical Fiber Cable
DC 5V
Serial
Device
TCP/IP
LAN
KE6920T (Rear)
Cat 5e/6 cable
Optical Fiber Cable
DC 5V
Serial
Device
Secondary
Primary
