ATEN KE6900T - KE6900 A; KE6940 A Point-to-Point Installation 2 of 2

KVM over IP Matrix System User Manual
90
Note: The diagram above shows KE6900AT and KE6900AR. The KE6940A
installation is the same except that an additional DVI monitor can be
connected at each end for a dual-display setup.
KE6900A / KE6940A Point-to-Point Installation 2 of 2
Note: The serial port on the transmitter (shown above) connects to the
computer, while the serial port on the receiver (not shown) connects to
a serial device (optional).
KE6900AT (Front)
5
3
4
USB DVI-D KVM
cable
