ATEN KE6900T - Receiver Dual Rack Mount

UPS User Manual
416
Receiver Dual Rack Mount
KE8950R is the example used here.
1. Remove the eight screws and plastic guards from the receiver units.
2. Remove four screws from the units and then use the same screws to secure
the units together with the link bracket provided with the kit.
