KVM over IP Matrix System User Manual
164
Properties
There are two versions of Properties for KE Series, a Regular Version, and a
Slim Version.
The Properties tab allows you to configure the Receiver’s settings.
Note: KE8900ST, KE8900SR, and KE9900ST are
Slim Version.
Regular Version
Item Description
Mode Select Extender mode for simple one-to-one (Transmitter to
Receiver) setups that are managed with the Receiver’s OSD
menu.
Select Matrix mode to manage devices and connections from
the KVM over IP Matrix Manager web GUI. This mode is for
advanced administration of Transmitter to Receiver connections
(see Browser / Telnet Operation, page 205).
Properties If you selected Extender mode (above) set the Transmitter IP
address for the Receiver’s Video, Audio, USB, and RS232
source signals.
If you selected Matrix mode (above) the Properties will be
grayed out. Use Channels to configure the Transmitter
connections (see Browser / Telnet Operation, page 205).
