KVM over IP Matrix System User Manual
210
Adding Transmitters and Receivers
1. On the installation wizard for transmitters and receivers, select options to
locate the devices:
2. Check the boxes under Transmitter / Receiver to select the devices you
want to add, then click Next.
3. Under Assign IP Address select an option to configure the network
settings, then click Next.
Item Description
Search Local Check this box and click the Refresh button to search the
local area network for Transmitters/Receivers.
Search Subnet Check this box, enter a subnet IP and then click the
Refresh button to search the subnet for Transmitters/
Receivers.
Transmitter / Receiver Displays the number of Transmitters and Receivers that
have been discovered on the network. Use the check
boxes next to the Transmitters/Receivers to select the
devices you want to add.
The Refresh button provides a way to update the
information currently being displayed in the install wizard
window.
