Appendix
409
KE9900ST
Function KE9900ST
Connectors KVM Ports 1 x USB Type B Female (White)
1 x DisplayPort Female (Black)
1 x DB-9 Male (Black)
Power 1 x DC Jack (Black)
1 x 3-Pole Terminal Block Connector (Green)
LAN 1 x RJ-45 (Black)
Switches Reset 1 x Semi-recessed Pushbutton
LEDs 10/100/1000 Mbps 1 (10: Orange / 100: Orange & Green / 1000:
Green)
Power 1 x Blue
Emulation Keyboard / Mouse USB
Power Consumption DC 5 V, 4.75 W; DC 48 V, 6.97 W
Video Resolution Up to 1920 x 1200 @ 60 Hz
Environment Operating Temp. 0 – 50 ºC
Storage Temp. -20 – 60 ºC
Humidity 0–95% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.65 kg (1.43 lb)
Dimensions
(L x W x H)
18.20 x 11.75 x 2.87 cm
(7.17 x 4.63 x 1.13 in.)
