Chapter 3. OSD Operation
187
Array Mode
Note that Array Mode is not supported by slim KVM over IP Receivers.
In Array Mode the screen is divided into a grid of panels, with each panel
showing the video display of a particular Channel. Right-click a panel and
select a mode to connect: E: Exclusive, O: Occupy, S: Share, V: View Only,
X: Exit. While the mouse cursor hovers over a panel displaying video, if audio
is being sent from that Transmitter, it can be heard at the Receiver.
No. Item Description
1 Next Arrow Use these two buttons to navigate to the next page or to
the end of the list if there are more Channels available
than can be seen on the page.
2 Previous Arrow Use these two buttons to navigate to the previous page
or to the beginning of the list if there are more Channels
available than can be seen on the page.
3 Grid Selection Select a range for how many Channels you want to
display. Options are: 2x2, 3x3, 4x4, 5x5, and 6x6.
