KVM over IP Matrix System User Manual
186
10 EDID Mode When a Transmitter's EDID is configured, depending
on its setting, different buttons will or won't appear to
configure the Receiver's EDID for the connection.
The following rules apply to the Receiver’s OSD
according to the Transmitter's EDID setting:
Under Default or Auto EDID mode, no EDID
button appears as there is nothing to configure.
Under Manual or Remix EDID mode, the EDID
button appears allowing you to select Manual
EDID or Remix EDID.
Note: For KE9950 / KE9952 / KE8950 / KE8952,
when set to Manual EDID mode with a resolution of
2560 x 1440 @ 60 Hz, make sure to enable
Reduced Blanking Mode, otherwise it must be
adjusted to 2560 x 1440 @ 30 Hz.
Click Manual or Remix to adjust the EDID setting
locally.
To set the Transmitter’s EDID Mode, see Properties,
page 175.
11 Logout Click this button to log out of the Connection Page.
12 Go to Configuration
Window
Click this button to return to the main OSD screen.
No. Item Description
