Chapter 3. OSD Operation
165
RS232 Settings Configure the serial device settings for the Receiver. The
default settings are:
Baud Rate: 9600
Parity: None
Data Bits: 8 bits
Stop bits: 1 bit
Flow Control: None
Enable Media Select which type of media the Receiver can stream from
Transmitters: Video, Audio, USB, and RS232. For KE8950
Series models, use the radio button to set the source of the
audio signal: HDMI, Analog, or Both.
Manager
Address
Set the IP address and Port number of the computer running
the KVM over IP Matrix Manager. The default port number is
9110.
Beeper Check this box to allow the Receiver to beep when configuration
changes are made to it.
Touch Screen
Calibration
Use this button to calibrate the surface of a USB touch screen
connected to the unit. When the calibration screen appears,
touch the flashing + symbol at each corner until the process is
complete.
Item Description
