ATEN KE6900T User Manual

Chapter 1. Introduction
65
2 LAN LED This LED indicates the network status.
 Lights when connected to the LAN and blinks when the
Ethernet connection is active:
 Orange: 10 Mbps
 Orange + Green: 100 Mbps
 Green: 1000 Mbps
 Off when not connected to the LAN.
3 power LED Lights blue to indicate the unit is turned on.
4 LAN port The cable that connects the unit to the LAN plugs in here.
5 RS-232 port This RS-232 serial port is for connecting to the computer for
serial control.
Note: When a LAN connection is detected serial
commands bypass the KE8900ST and are sent across the
network to the receiver. When no LAN connection is
detected serial commands are automatically directed to the
KE8900ST for local configuration and control.
6 USB Type-B port The USB port that links the Transmitter to the computer.
7 HDMI input The cable from the local HDMI monitor plugs in here.
8 3-pole terminal
block
Insert DC + and - wires (DC 12 ~ 48 V) to the terminal block
for power input.
9 power jack The cable from the DC power adapter connects here.
10 grounding
terminal
The wire used to ground the unit connects here.
