Chapter 6. System Status
271
2. After filling in the information, click a Receiver, select Select TX and use
the drop-down menu select a Transmitter; or use Transmitter List at the
bottom of the page to drag-and-drop Transmitters to Receivers to create
the connection.
Access Mode This defines how the Transmitter in a Profile can be
accessed by Receivers when multiple users attempt to
access it.
View Only: Receivers only have view access to the
Transmitter’s video display.
Share: All users accessing the Transmitter can
simultaneously share control of the Transmitter. Input
from the users is placed in a queue and executed
chronologically.
Occupy: Set a time threshold for Receivers whose
Access Mode has been set to Occupy If there is no
activity from the Receiver occupying the port for the
amount of time set here, the Receiver is timed out and
the port is released. The first Receiver to send keyboard
or mouse input after the port has been released gets to
occupy the port. Input a value from 1 to 240 seconds.
Exclusive: The first Receiver to access the Transmitter
has exclusive control over the Transmitter. No other
users can view the Transmitter. The Timeout function
does not apply to Transmitters which have this setting.
Login Check Check this box to require a user to be logged in to the
Receiver before a Profile can connect it to a Transmitter.
When enabled, a user must be logged into the Receiver
or it will not connect to the Transmitter when the Profile is
initiated.
Lock OSD Checking this box will lock the Receiver’s OSD screen
when the Profile connects it to a Transmitter.
Location Use the drop-down menu to select a location to filter the
Receivers displayed on the page.
Click this icon to show individual Receivers.
Click this icon to show only video wall Receivers.
Click this icon to show only Receiver Group Receivers.
Save Click to save the changes.
Cancel Click to exit without saving.
Item Description
