KVM over IP Matrix System User Manual
30
6 RS-232 port This RS-232 serial port is for connecting to a serial
terminal.
7 console ports The unit’s USB keyboard and USB mouse plug into
these ports.
8 LAN port The cable that connects the unit to the LAN plugs in
here.
This port is PoE enabled* for KE6912 for power
redundancy or cable management.
*Requires power board version B01G or later (see
PoE Power Redundancy on page 75 for more details).
9 SFP slot The Gigabit Ethernet (GbE) optical fiber cable that
connects the unit to the LAN plugs in here.
10 DVI-D output The cable from the local DVI monitor plugs in here.
11 power jack (KE6910T
only)
Connect a second power source for power
redundancy.
No. Component Description
