5. Troubleshooting
Situation Solution
The Board ID of all other boards
are also NO T accessible. This
may indicates a malfunction I²C
functionality on the P MP board.
1. Reboot the projector.
2. Replace the P MP board. Se e "Replacing the PMP board", page 156.
Malfunction Fan Control bo ard. Replace the Fan Control board. S ee "Replacing the F an control board", page 278.
Code 6046: “Board id: fan control board read error” (Error)
Situation Solution
Malfunction Fan Control board. The
projector c an not read from the
installed Fan Control board.
In case no other “board read errors” appears, replace the Fan C ontrol board. See
"Replacing the Fan control board", page 278.
Malfunction internal RS485
communication line. The MCB, LIM
and CLO also reports “read er rors”.
Disconnect the board s one by one from the internal RS4 85 line until this error disappears.
Replace the board which makes this error goes away. See chapter XXXX , to known
which boards are using the internal RS485 communication line. If the problem remains
replace the P MP. See "Replacing the PMP board", page 156.
Code 6047: “Board id: fan control board write error” (Error)
Situation Solution
Malfunction Fan C ontrol board.
The projector can not write to the
installed Fan Control board.
Replace the Fan Control board. "Replacing the Fan control board", page 278.
Code 6048: “Board id: motor control board unknown format” (Warning)
Situation Solution
Old projector softwa re installed. Th e
ID parameters of the Motor Control
board are written in a format which is
not known by the projector software.
Check if the v ersion o f the installed projector software is the latest available v ersion. T he
latest version can be downloaded from h
ttps://my.barco.com.
Motor Control board has invalid
firmware.
Replace the Motor Control board. See "Replacing the motor control board (MCB)",
page 283.
Corrupt pr ojector s oftware. Reinstall the latest projector software.
Code 6049: “Board id: motor control board not accessible” (Error)
Situation Solution
Only the ID parameters of the Motor
Control board are not accessible.
The ID parameters of all other
boards are accessible.
Ignore this error m essage unless other functionality of the M otor Control board fails as
well. If so, replace the Motor Control board. See "Replacing the motor control board
(MCB)", page 283.
The Board ID of all other boards
are also NO T accessible. This
may indicates a malfunction I²C
functionality on the P MP board.
1. Reboot the projector.
2. Replace the P MP board. Se e "Replacing the PMP board", page 156.
Malfunction M otor Control boa rd. R eplace the M otor Control board. See "Replacing the motor control board (MCB)",
page 283.
Code 6050: “Board id: motor control board read error” (Error)
Situation Solution
Disconnected wire unit between the
Power Distribution b oard and the
Motor Control boar d.
1. Check if the wire unit (reference 1 image 5-9) is connected with the Motor Control
board.
2. Check if the wire unit (reference 22 image 5-10) is co nnected with the P ower
Distribution Board.
Malfunction M otor Control board.
The projector can not read from the
installed M otor Control board.
In case no other “board read errors” a ppears, replace the Motor Control board. See
"Replacing the m otor control boar d (MCB)", page 283.
Malfunction internal RS485
communication line. T he FCB, LIM
and CLO also reports “read er rors”.
Disconnect the boards one by one from the internal R S485 line until this error
disappears. Replace the board which mak es this error goes away. See chapter XXXX,
to know n which boards ar e using the internal RS485 comm unication line. If the problem
remains replace the PMP.
R5905312 HDF W SERIES 24/01/2013 47
