5. Troubleshooting
1
Image 5-9
22
Image 5-10
Code 6051: “Board id: motor control board write error” (Error)
Situation Solution
Malfunction M otor Control board.
The projector can not write to the
installed M otor Control board.
Replace the Motor Control board. See "Replacing the motor control board (MCB)",
page 283.
Code 6052: “Board id: lamp info module unknown format” (Warning)
Situation Solution
Old projector software installed.
The ID parameters of t he Lamp
Info Module are written in a format
which is not known by the projector
software.
Check if the v ersion o f the installed projector software is the latest available v ersion. T he
latest version can be downloaded from h
ttps://my.barco.com.
Lamp Info M odule has invalid
firmware.
Replace the Lamp House. S ee "Removal of the lam p house", page 119.
Corrupt pr ojector s oftware. Reinstall the latest projector software.
Code 6053: “Board id: lamp info module board not accessible” (Error)
Situation Solution
Only the ID parameters of the Lamp
Info module are not accessible. The
ID p a rameters of all other boards are
access ib le .
Ignore this e rror message unless other functionality of the La mp Info module fails as
well. If so, replace the Lam p Info module. See XXXX X.
The Board ID of all other boards
are also NO T accessible. This
may indicates a malfunction I²C
functionality on the P MP board.
1. Reboot the projector.
2. Replace the P MP board. Se e "Replacing the PMP board", page 156.
Malfunction Lamp Info module
(reference 3 XXXX).
Replace the Lamp Info module. The Lamp Info M odule is located inside the Lamp
House, behind the blue socket. See XXXX.
Code 6054: “Board id: lamp info module read error” (Error)
Situation Solution
No Lamp House installed.
Install the Lamp House. See "Installation of the lamp hou se", page 121.
Damaged La mp Info module
socket s.
1. Check if the blue socket at the front of the Lamp Hous e (reference 1 image 5-11) is
not damaged. If damaged, replace the Lamp Info module. See "Lamp info m odule
replacement", page 138.
2. Check if the blue soc ket inside the Lamp House compartment (reference 2
image 5-12) is not damaged. If damaged, replace the main wire tree.
Wire unit of the Lamp Info module
socket is disc onnected from the
Power Backplane.
Reconnect the wire unit (reference 6 image 5- 13) with the Power distribution board.
48 R5905312 HDF W SERIES 24/01/2013
