147.16 Torque init stress 1
Torque init stress of the slave drive at torque coupling at speed limit torque init stress
Z147.17– (at slave functionality only, i.e. Z147.1– Bit 1...0 = 10, see ZFig. 71– on page
254). If parameter Z147.1– Bit 12 is set, this additional torque takes effect correspond-
ingly (see ZFig. 73– on page 256).
147.17 Speed limit torque init stress 1
Speed limit for the torque init stress 1 Z147.16– at torque coupling (at slave functionality
only, i.e. Z147.1– Bit 1...0 = 10, see ZFig. 71– on page 254). If parameter Z147.1–
Bit 12 is set, this additional torque takes effect correspondingly (see ZFig. 73– on page
256). The limit effects bipolar, thus means in both directions of revolution.
147.18 Torque init stress pt1 time constant
Time constant of PT1 element to connect the torque init stress to the slave at torque cou-
pling (at slave functionality only, i.e. Z147.1– Bit 1...0 = 10, see ZFig. 71– on page 254).
147.19 Torque set value master
Display of the torque set value of the master at torque coupling in the dimensions for
transmission via fieldbus.
This parameter must be sent cyclic from the master to the slave.
At external master-slave communication this parameter must be sent via cross commu-
nication (fieldbus) or analog inputs/outputs. See also ZCross communication– on page
256.
At internal master-slave communication an external transmission is not required.
NOTE!
The parameterized torque init stress is set only at the time when both the speed cou-
pling factor master and slave Z147.5–, Z147.6– are 1.
