2000X energy Power Supply Chapter 6: Operation
Instruction Manual Using the System Configuration Menu
011-003-991 EN 6-109
Setting the Amplitude Control
NOTE
i
If you set the Amplitude Control to External, you must connect an external voltage-scaling
device to the I/O connector. If nothing is connected, only 50% amplitude will be reached.
Take this action… To get this result…
Press the Select key that corresponds to
Amp Control.
Press the Select key repeatedly to toggle
between Int and Ext. Press the Enter key
on the numeric keypad when you have set
Amp Control to the state you want.
SYS CONFIG Pg11of19
Beepers>
P/S Settings>
Amp Control =Int
Select
Select
Select
SYSCONFIG Pg11of19
Beepers>
P/S Settings>
Amp Control =Ext
Select
Select
Select
