Chapter 7: Maintenance
System Alarm Tables
7-30 011-003-991 EN
Force B> Pressure The force value was selected while the set
pressure was 80 psi, then the set pressure was
changed to 60 psi.
The force value must be re-entered.
Force/Lmt Conflict Weld force is equal to or greater than the plus
reject weld force limit. This alarm can only occur if
force stepping is off.
Either raise the reject limit or lower the
weld force.
Force/Lmt Conflict Weld force is equal to or greater than the plus
suspect weld force limit. This alarm can only occur
if force stepping is off.
Either raise the suspect limit or lower the
weld force.
Force/Lmt Conflict Weld force is equal to or less than the minus reject
weld force limit. This alarm can only occur if force
stepping is off.
Either raise the reject limit or lower the
weld force.
Force/Lmt Conflict Weld force is equal to or less than the minus
suspect weld force limit. This alarm can only occur
if force stepping is off.
Either raise the suspect limit or lower the
weld force.
Force/Lmt Conflict Force B is equal to or greater than the plus reject
weld force limit. This alarm can only occur if force
stepping is on.
Either raise the reject limit or lower the
force B setting.
Force/Lmt Conflict Force B is equal to or greater than the plus suspect
weld force limit. This alarm can only occur if force
stepping is on.
Either raise the suspect limit or lower the
force B settings.
Force/Lmt Conflict Force B is equal to or less than the minus reject
weld force limit. This alarm can only occur if force
stepping is on.
Either lower the reject limit or raise force
B setting.
Force/Lmt Conflict Force B is equal to or less than the minus suspect
weld force limit. This alarm can only occur if force
stepping is on.
Either lower the suspect limit or raise the
force B setting.
Force Step Conflict The force step at power is equal to or greater than
the plus reject peak power limit. This alarm cannot
occur in peak power welding mode.
Either raise the reject limit or lower the
step at power setting.
Force Step Conflict The force step at power is equal to or greater than
the plus suspect peak power limit. This alarm
cannot occur in peak power welding mode.
Either raise the suspect limit or lower the
step at power setting.
Force Step Conflict The force step at energy is equal to or greater than
the plus reject energy limit. This alarm cannot
occur in energy welding mode.
Either raise the reject limit or lower the
step at energy setting.
Force Step Conflict The force step at energy is equal to or greater than
the plus suspect energy limit. This alarm cannot
occur in energy welding mode.
Either raise the suspect limit or lower the
step at energy setting.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
