Branson 2000X - Page 251

2000X energy Power Supply Chapter 7: Maintenance
Instruction Manual System Alarm Tables
011-003-991 EN 7-33
2000a
2000dt
2000e
Pwr S/R Limit
Cross
The minus reject power limit is equal to or greater
than the minus suspect power limit.
Change the - reject power limit or -
suspect power limit through the Alarm
Information screen or Setup menu.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the minus reject absolute limit.
Either increase the reject distance limit or
decrease the rapid traverse distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the minus suspect absolute limit.
Either increase the suspect distance limit
or decrease the rapid traverse distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the plus reject absolute limit.
Either increase the reject distance limit or
decrease the rapid traverse distance
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the plus suspect absolute limit.
Either increase the suspect distance limit
or decrease the rapid traverse distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the plus reject trigger limit.
Either increase the reject distance limit or
decrease the rapid traverse distance
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the plus suspect trigger limit.
Either increase the suspect distance limit
or decrease the rapid traverse distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the minus reject trigger limit.
Either increase the reject distance limit or
decrease the rapid traverse distance
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the minus suspect trigger limit.
Either increase the suspect distance limit
or decrease the rapid traverse distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the absolute distance cutoff. This alarm can
occur in all weld modes except absolute.
Either increase the absolute cutoff
distance or decrease the rapid traverse
distance.
Rapid Trav. Conflict The rapid traverse distance is equal to or greater
than the absolute distance. This alarm can occur
only in the absolute welding mode.
Either increase the absolute cutoff
distance or decrease the rapid traverse
distance.
Sync Setup The sync input pin and the sync output pin are not
both defined.
Define missing sync pin.
Ext Signal Ext Start requires both an input pin and an output
pin to function. One of the pins is not defined.
Define both and input and an output pin
for the SV Interlock.
Sync Setup The sync input pin and the sync output pin are not
both defined.
Define missing sync pin.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
