Chapter 7: Maintenance
System Alarm Tables
7-34 011-003-991 EN
Sys. Pres. Incorrect The system pressure is out of tolerance (+/-3 PSI).
The pressure is read only after five seconds of idle
time while in ready. This alarm does not remove
the ready signal because that would prevent entry
into horn down. Horndown is the only place where
the pressure can be viewed for adjustment.
Go to horndown and adjust the system
pressure to either 60 psi (+/- 3 psi) or 80
psi (+/- 3 psi).
2000a
2000dt
2000e
+ - Time Limit
Crossed
The suspect limits for time that you have entered
are reversed.
Change the suspect time limits through
the Alarm Information screen or Setup
menu.
2000a
2000dt
2000e
+ - Time Limit
Crossed
The reject limits for time that you have entered are
reversed.
Change the reject time limits through the
Alarm Information screen or Setup menu.
2000a
2000dt
2000e
Time S/R Limit
Cross
The plus reject time limit is equal to or less than the
minus suspect time limit.
Change the +reject time limit or - suspect
time limit through the Alarm Information
screen or Setup menu.
2000a
2000dt
2000e
Time S/R Limit
Cross
The plus suspect time is equal to or less than the
minus reject time limit.
Change the +suspect time limit or - reject
time limit through the Alarm Information
screen or Setup menu.
2000a
2000dt
2000e
Time S/R Limit
Cross
The plus reject time limit is equal to or less than the
plus suspect time limit.
Change the +reject time limit or +suspect
time limit through the Alarm Information
screen or Setup menu.
2000a
2000dt
2000e
Time S/R Limit
Cross
The minus reject time limit is equal to or greater
than the minus suspect time limit.
Change the - reject time limit or - suspect
time limit through the Alarm Information
screen or Setup menu.
2000a
2000dt
2000e
Timeout Conflict The plus reject time limit is equal to or greater than
the
maximum timeout value.
Change the +reject time limit or
maximum timeout value through the
Alarm Information screen or Setup menu.
2000a
2000dt
2000e
Timeout Conflict The minus reject time limit is equal to or greater
than the
maximum timeout value.
Change the - reject time limit or maximum
timeout value through the Alarm
Information screen or Setup menu.
2000a
2000dt
2000e
Timeout Conflict The plus suspect time limit is equal to or greater
than the
maximum timeout value.
Change the +suspect time limit or
maximum timeout value through the
Alarm Information screen or Setup menu.
2000a
2000dt
2000e
Timeout Conflict The minus suspect time limit is equal to or greater
than the maximum timeout value.
Change the +suspect time limit or
maximum timeout value through the
Alarm Information screen or Setup menu.
Trigger Delay
Conflict
External trigger delay has been enabled in weld
setup, but no input pin has been defined.
Assign pin in System Configuration
Menu.
Trigger Delay
Conflict
External trigger delay and pretrigger are both on. Turn one off.
Table 7.8 Setup Alarms and Messages, with Probable Cause
and Corrective Action (Continued)
Model
Display
Message
Alarm Condition/Cause Corrective Action
