Names of Parts and Their Functions
94LS-005
Fr
ont Side
Check these parts on the front when operating the machine.
Front Side(P. 9)
● Use the oper
ation panel to operate the machine and congure the settings.
Operation Panel(P. 13)
● Place the original on the platen glass or in the feeder when scanning, sending a fax, or cop
ying.
Feeder(P. 18)
● Load printing and cop
ying paper into the paper drawer.
Paper Drawer(P. 19)
Rear Side
Check the r
ear parts when installing and connecting the machine and when clearing paper jams.
Rear Side(P. 11)
Interior
Check the interior of the machine when r
eplacing toner cartridge.
Interior(P. 12)
About the Machine
8
