Preview Area

You can check the settings you made in this area.

•

Dialog Area

This allows you to set the print conditions and perform a print job.

For more information about Dialog Area, see "Dialog Area." ➔ P.185

•

Status Bar

This shows the message,

Pages and Output Size.

Preview Main Window

iPF8400S

User's Guide

Windows Software Preview

184
