Canon IPF8400S - Removing the Roll Holder from Rolls

7
Holding the Roll Holder flange (a), remove the holder
from the Roll Holder Slot.
Note
• For instructions on removing the Roll Holder from rolls, see "Removing the Roll Holder from Rolls." ➔ P.479
8
Lower the Ejection Guide and close the Top Cover.
Note
• To load new paper in the printer at this point, see "Loading Rolls in the Printer." ➔ P.471
• Clean inside the top cover before loading paper.
(See "Cleaning Inside the Top Cover.") ➔ P.840
Removing the Roll Holder from Rolls
Removing the Roll Holder from Rolls
1
Lift the Holder Stopper lever (a) from the shaft side to
unlock it. Holding the Holder Stopper at the position in-
dicated (b), remove it from the Roll Holder.
iPF8400S Removing the Roll Holder from Rolls
User's Guide
Handling and Use of Paper Handling rolls
479
