Canon IPF8400S - Media Take-Up Unit(Optional)

Media Take-up Unit(Optional)
Media Take-up Unit(Optional)
Main Unit
a
Left Media Take-up Unit
Load the Rewind Spool here.
b Right Media Take-up Unit
Load the Rewind Spool here. Includes the Media Take-up Unit Power button, ▲ and ▼ buttons to advance or
rewind paper, and a power cord.
c
Rewind Spool
Winds documents printed on rolls.
d 3-inch Adapter
When rewinding rolls with 3-inch paper cores, attach the adapter to the Rewind Spool.
e Media Take-up Sensor
A sensor for automatically rewinding rolls.
Weight
a
Weight Roll (6)
Weights required when rewinding rolls. Use one weight roll or combine two (with a Weight Joint ), depending
on the roll width.
b Weight Joint
Fastens two weight rolls.
Media Take-up Unit(Optional)
iPF8400S
User's Guide
