Weight Flange (2 sets)

Attached to the ends of Weight Roll to adjust the weight. Use Weight Flange 1 or Weight Flange 2, depending

on the type of paper. (See "Loading the Rewind Spool on the Media Take-up Unit.") ➔ P.508

iPF8400S

Media Take-up Unit(Optional)

User's Guide

Printer Parts Printer parts

615
