2

Execute Standard in Head Posi. Adj..

Note

• If paper rubs against the Printhead or becomes jammed during Printhead height adjustment, try selecting a

higher level in Head Height and performing Standard again.

iPF8400S

Enhancing Printing Quality

User's Guide

Adjustments for Better Print Quality Adjustment for high-precision printing

711
