Executing Color Check

1

Open the Color Measurement sheet.

2

Select the printer you want to execute color check on

from the Printer list.

3

Click the Color Check button.

Executing Color Check

iPF8400S

User's Guide

Color Management Color Calibration Management Console (Windows)

768
