10-14

k Inserting an Image (Picture)

The following table shows the image file sizes that are supported for insertion into an eActivity

file.

Width × Height

(dots)

Size Example Screen

(a) 384 × 216 This is the overall screen size for this

model. The graphic images stored

in capture memory (page 1-36) are

this size. The 48 vertical dots that are

outside of the eActivity display range

can be displayed by scrolling.

(b) 384 × 192 This is the screen size when a graph

screen is saved to picture memory

(page 5-21).

• The line on the eActivity workspace screen where an image is inserted is called a “picture

line”. You can insert only one image per picture line, and you cannot enter text or numbers

into the same line where a picture line is inserted.

• You can insert a 16-bit g3p format file or a screen image (3-bit g3p format file) saved to

capture memory (page 1-36).
