© AGRGS 2016 | Data subject to change without notice
67385867493098462 | en, eu, V5, 07. Oct 2016, page 10
Element
Use
CONF1
Dip-unit. Selects controller configuration.
RST
Controller IP-settings reset jumper.
K1
Switching relay 1 LED (NO1-COM1-NC1).
K2
Switching relay 2 LED (NO2-COM2-NC2).
K3
Switching relay 3 LED (NO3-COM3-NC3).
K4
Switching relay 4 LED (NO4-COM4-NC4).
PWR
Controller power supply status LED (green).
RX
Data reception LED (yellow).
TX
Data transmission LED (red).
DCD
Determine supply voltage type OFF jumper.
FD
Fire alarm inputs OFF jumper.
T1
Ethernet-link connector.
Table 1. Key elements of Pic 1
