CONSOLE AI | Managing Channels (CP2) | 190
Crosspoint Type Description
Gated Connections between a microphone and any other channel can be
Gated or Non-Gated. If you choose Gated, the connection between
the two channels follows whatever gating rules are assigned to the
microphone. Gated crosspoints are gold.
Non-Gated Connections between a microphone and any other channel can
be Gated or Non-Gated. If you choose Non-Gated, the connection
between the two channels doesn’t follow any gating rules. Non-gated
crosspoints are blue.
Pre-AEC Setting a Pre-AEC crosspoint in the Matrix bypasses the cross-pointed
input audio from the AEC (Acoustic Echo Cancellation) reference. This
is primarily used for sound reinforcement applications to prevent mic
input channel audio from being degraded by AEC artifacts. Pre-AEC
crosspoints are purple.
Crosspoint Connections between channels that don’t involve microphones or
processing blocks are simple crosspoints. Regular crosspoints are
green.
Remove a Channel Route
20.To remove a channel route, click the route to select it.
21.Press the Delete key OR right-click the route and choose Delete > Route(s) from the context menu.
Add a Reference
22.To add a standard reference, see Adding Standard References (CP2).
Note:
For more information about references, see About References.
23.To add a custom reference, see Adding Custom References (CP2).
24.To assign a standard or custom reference, see Assigning References (CP2).
Add Channels to a Channel Group
25.Select a channel icon OR hold down the CTRL or SHIFT keys and select multiple channel icons OR
drag around several channel icons to select more than one.
26.Right-click any of the selected channels; from the context menu that appears, choose Create and then
Group.
The channels are added to a group. The group icon shows the number of channels in the group in
parentheses.
Add Channels to a Gating Group
27.Add a gating group to the project by dragging a Gating Group resource at the bottom of the Assigned
Resources area on the left into the main FlowView area.
28.Double-click the gating group icon you just dragged into the FlowView area.
The Gating Groups dialog box appears:
