To establish the rule for a previously created CPU Access Profile:
To configure the Access Rules for IP, open the CPU Access P rofile L ist window and click Add/View R ules for an
IPv6 entry. This will open the following window.
Figure 7 - 43 CPU Access Rule List window for IPv6
To remove a previously created rule, click the corresponding Delete R ules button. To add a new Access Rule, click
the Add Rule button:
Figure 7 - 44 Add Access Rule window for IPv6
To set the Access Rule for IPv6, adjust the following parameters and click Apply.
Parameter Description
Access ID (1-100) Type in a unique identifier number for this access. This value can be set from 1 to 100.
Class Enter an IPv6 Class. The class can be between 0 – 255.
Flow Label
Configuring this field, in hex form, will instruct the Switch to examine the flow label field of the
IPv6 header. This flow label field is used by a source to label sequences of packets such as non-
default quality of service or real time service packets.
Action Select Permit to specify that the packets that match the access profile are forwarded by the
Switch, according to any additional rule added (see below).
Select Deny to specify the packets that match the access profile are not forwarded by the Switch
and will be filtered.
Flow Label
Configuring this field, in hex form, will instruct the Switch to examine the flow label field of the
IPv6 header. This flow label field is used by a source to label sequences of packets such as non-
default quality of service or real time service packets.
