xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
113
group_id - Specifies the group ID used.
<value 1-4> - Enter the group ID used here. This value must be between 1 and 4.
deny - Specify the packets that match the access profile are filtered by the switch.
time_range - (Optional) Specify the name of this time range entry.
<range_name 32> - Specify the name of this time range entry. The maximum length is 32
characters.
delete access_id - Specify to delete the access ID.
<value 1-256> - Specify the value between 1 and 256.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure an access list entry:
DGS-3420-28SC:admin#config access_profile profile_id 1 add access_id 1 ip vlan
default source_ip 20.2.2.3 destination_ip 10.1.1.252 dscp 3 icmp port 1 permit
Command: config access_profile profile_id 1 add access_id 1 ip vlan default
source_ip 20.2.2.3 destination_ip 10.1.1.252 dscp 3 icmp port 1 permit
Success.
DGS-3420-28SC:admin#
5-4 show access_profile
Description
This command is used to display the current access list table.
Format
show access_profile {[profile_id <value 1-6> | profile_name <name 1-32>]}
Parameters
profile_id - (Optional) Specify the index of the access list profile.
<value 1-6> - Specify the profile ID between 1 and 6.
profile_name - (Optional) Specify the name of the access list profile.
<name 1-32> - Specify the profile name between 1 and 32.
Restrictions
None.
