D-Link xStack DGS-3420 Series User Manual

xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
114
Example
To display the current access list table:
DGS-3420-28SC:admin#show access_profile
Command: show access_profile
Access Profile Table
Total User Set Rule Entries : 3
Total Used HW Entries : 19
Total Available HW Entries : 1005
================================================================================
Profile ID: 1 Profile Name: 1 Type: Ethernet
Mask on
VLAN ID : 0xFF
Source MAC: FF-FF-FF-FF-FF-00
802.1p
Available HW Entries: 254
---------------------------------------------------------------------------------
Rule ID : 1 Ports: 1-10
Match on:
VLAN ID : 2 Mask : 0xFFF
Source MAC : 00-01-02-03-04-00
Action:
Permit
Replaced Priority to 2
Replace DSCP to 33
Matched Count: 0 packets
---------------------------------------------------------------------------------
Rule ID : 256 (auto assign) Ports: -
Match on:
VLAN ID : 8
Source MAC : 00-01-02-03-04-00
802.1p
Action:
Deny
===================================================================================
Profile ID: 3 Profile Name: 3 Type: IPv4
Mask on
Source IP : 255.255.255.0
TCP
Source Port : 0x00FF
Available HW Entries: 254
---------------------------------------------------------------------------------
Rule ID : 4 Ports: 1-28
Match on:
Source IP : 192.168.1.0
TCP
