xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
568
Format
show mcast_filter_profile {[ipv4 | ipv6]} {[profile_id <value 1-60> | profile_name <name 32>]}
Parameters
ipv4 - (Optional) Specify to display an IPv4 multicast profile.
ipv6 - (Optional) Specify to display an IPv6 multicast profile.
profile_id - (Optional) Specify the ID of the profile. If both profile_id and profile_name are not
specified, all profiles will be displayed.
<value 1-60> - The profile ID must be between 1 and 60.
profile_name - (Optional) Specify to display a profile based on the profile name. If both profile_id
and profile_name are not specified, all profiles will be displayed.
<name 32> - The profile name can be up the 32 characters long.
Restrictions
None.
Example
To display all the defined multicast address profiles:
DGS-3420-28SC:admin#show mcast_filter_profile
Command: show mcast_filter_profile
Profile ID Name Multicast Addresses
---------- --------------------------- -----------------------------
1 MOD 234.1.1.1–238.244.244.244
2 customer 224.19.62.34–224.19.162.200
Total Entries: 2
DGS-3420-28SC:admin#
49-6 config limited_multicast_addr
Description
This command is used to configure the multicast address filtering function on a port or VLAN. When
there are no profiles specified with a port or VLAN, the limited function is not effective. When the
function is configured on a port or VLAN, it limits the multicast group operated by the IGMP/MLD
snooping function and layer 3 function. If the IPv4 or IPv6 option is not specified, IPv4 is implied.
Format
config limited_multicast_addr [ports <portlist> | vlanid <vlanid_list>] {[ipv4 | ipv6]} {[add
[profile_id <value 1-60> | profile_name <name 32>] | delete [profile_id <value 1-60> |
profile_name <name 32> | all]] | access [permit | deny]}(1)
