xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
592
Format
config lldp_med ports [<portlist> | all] med_transmit_capabilities [all | {capabilities |
network_policy | power_pse | inventory}(1)] state [enable | disable]
Parameters
<portlist> - Specify a range of ports to be configured.
all - Specify to set all ports in the system.
med_transit_capabilities - Select to send the LLDP-MED TLV capabilities specified.
all - Select to send capabilities, network policy, and inventory.
capabilities – (Optional) Specify that the LLDP agent should transmit “LLDP-MED capabilities TLV.”
If a user wants to transmit LLDP-MED PDU, this TLV type should be enabled. Otherwise, this port
cannot transmit LLDP-MED PDU.
network_policy - (Optional) Specify that the LLDP agent should transmit “LLDP-MED network policy
TLV.”
power_pse - This TLV type indicates that LLDP agent should transmit 'LLDP-MED extended Power
via MDI TLV' if local device is PSE device.
inventory - (Optional) Specify that the LLDP agent should transmit “LLDP-MED inventory TLV.”
state - Enable or disable the transmitting of LLDP-MED TLVs.
enable - Enable the transmitting of LLDP-MED TLVs.
disable - Disable the transmitting of LLDP-MED TLVs.
Restrictions
Only Administrator and Operator-level users can issue this command.
Example
To enable transmitting of all capabilities on ports 1 to 2:
DGS-3420-28SC:admin#config lldp_med ports 1-2 med_transmit_capabilities all state
enable
Command: config lldp_med ports 1-2 med_transmit_capabilities all state enable
Success.
DGS-3420-28SC:admin#
51-13 show lldp_med ports
Description
This command is used to display LLDP-MED per port configuration for advertisement options.
Format
show lldp_med ports {<portlist>}
