xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide

770

Example

To display the setting of all port’s LED admin state:

DGS-3420-28SC:admin#show led

Command: show led

Port LED State: Enabled

DGS-3420-28SC:admin#
