xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
804
5 Strict
6 Strict
7 Strict
8 Strict
9 Strict
10 Strict
CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All
To show the scheduling mechanism on ports 1-10:
DGS-3420-28SC:admin#show scheduling_mechanism 1-10
Command: show scheduling_mechanism 1-10
Port Mode
----- ------
1 Strict
2 Strict
3 Strict
4 Strict
5 Strict
6 Strict
7 Strict
8 Strict
9 Strict
10 Strict
DGS-3420-28SC:admin#
5-9 config 802.1p user_priority
Description
This command is used to configure the way by which the switch will map an incoming packet, based
on its 802.1p user priority, to one of the eight available hardware priority queues on the switch. The
switch’s default is to map the following incoming 802.1p user priority values to the eight hardware
priority queues. The suggested mapping is shown in the following table. Users can change this
mapping by specifying the 802.1p user priority to assign to the <class_id>.
Priority in Frames
Priority Queue of ASIC
Remark
0
2
Mid-Low
1
0
Lowest
2
1
Lowest
3
3
Mid-Low
4
4
Mid-High
5
5
Mid-High
