xStack® DGS-3420 Series Layer 2 Managed Stackable Gigabit Switch CLI Reference Guide
805
6
6
Highest
7
7
Highest
Format
config 802.1p user_priority {ports [<portlist> | all]} <priority 0-7> <class_id 0-7>
Parameters
ports - (Optional) Specifies that port used for this configuration.
portlist - Specifies the range of ports to be configured.
all - Specifies that all the ports will be used for this configuration.
<priority 0-7> - Specify the 802.1p user priority to associate with the <class_id> (the number of the
hardware queue).
<class_id 0-7> - Specify the number of the switch’s hardware priority queue. The switch has eight
hardware priority queues available. They are numbered between 0 (the lowest priority) and 7 (the
highest priority).
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To configure an 802.1p user priority of 1 map to class ID of 3:
DGS-3420-28SC:admin#config 802.1p user_priority 1 3
Command: config 802.1p user_priority 1 3
Success.
DGS-3420-28SC:admin#
5-10 show 802.1p user_priority
Description
This command is used to display 802.1p user priority.
Format
show 802.1p user_priority {<portlist>}
Parameters
<portlist> - (Optional) Specifies the range of ports to be configured.
