S0602170K
Page 36
Axle (ZF AP 420R)
8. Remove backing plate and plate pack.
9. Remove thrust washer.
10. Remove lock plate.
NOTE: See “Special Tools” on page 15.
11. Loosen and remove slotted nut.
NOTE: See “Special Tools” on page 15.
Figure 25
Figure 26
Figure 27
Figure 28
