S0607080K
Page 75
Transmission and Torque Converter
(ZF 4WG-310)
4. Pull tapered roller bearing from plate
carrier.
5. Press spur gear K2 from the plate carrier.
6. Secure plate carrier using clamping ring
(S).
7. Remove shim.
8. Pull tapered roller bearing from plate
carrier.
CAUTION!
Pay attention to the released plate
carrier.
Figure 145
Figure 146
Figure 147
Figure 148
