S0607080K
Page 107
Transmission and Torque Converter
(ZF 4WG-310)
3. Heat inner bearing race and line it up until
contact is obtained.
4. Introduce spur gear until all inner plates
are accommodated.
5. Line up shim (e.g. s = 2.20 mm (0.0866 in),
see Example/page 106).
6. Heat inner bearing race (spur gear
bearing) and line it up until contact is
obtained.
CAUTION!
Use protective gloves.
CAUTION!
Use protective gloves.
Figure 242
Figure 243
Figure 244
Figure 245
