S0607080K
Page 126
Transmission and Torque Converter
(ZF 4WG-310)
11. Lift clutch KR/K2 slightly, displace it in
direction of arrow, and position clutch K3/
K4.
12. Now, remove the Special device again.
13. Cool down outer bearing race and insert in
into housing bore until contact is obtained.
14. Heat inner bearing race and assemble it
until contact is obtained.
15. Position oil baffle.
Figure 300
Figure 301
Figure 302
Figure 303
