Daewoo Mega 500-V - Page 617

S0709730K
Page 15
Power Steering Unit
Return to Master Table of Contents
9. Lift middle plate off housing. See Figure
17.
10. Remove O-ring from housing. See Figure
18.
11. Unscrew threaded bushing and remove it.
See Figure 19.
12. Remove cross pin. See Figure 20.
Figure 17
Figure 18
Figure 19
Figure 20
