S0709730K
Page 21
Power Steering Unit
Return to Master Table of Contents
8. Install two thrust washers and thrust
bearing over end of spool. See Figure 37.
The sequence of the parts installation is
shown in Figure 38.
9. Oil O-ring and backup ring and then install
them on an O-ring assembly tool. See
Figure 39.
Reference
Number
Description
1 Thrust Washer
2 Thrust Bearing
3 Thrust Washer
4 Spool
5 Sleeve
Figure 37
Figure 38
Figure 39
